An Introductory Course of Quantitative Chemical Analysis / With Explanatory Notes

ALKALIMETRY AND ACIDIMETRY

GENERAL DISCUSSION

!Standard Acid Solutions! may be prepared from either hydrochloric, sulphuric, or oxalic acid. Hydrochloric acid has the advantage of forming soluble compounds with the alkaline earths, but its solutions cannot be boiled without danger of loss of strength; sulphuric acid solutions may be boiled without loss, but the acid forms insoluble sulphates with three of the alkaline earths; oxalic acid can be accurately weighed for the preparation of solutions, and its solutions may be boiled without loss, but it forms insoluble oxalates with three of the alkaline earths and cannot be used with certain of the indicators.

!Standard Alkali Solutions! may be prepared from sodium or potassium hydroxide, sodium carbonate, barium hydroxide, or ammonia. Of sodium and potassium hydroxide, it may be said that they can be used with all indicators, and their solutions may be boiled, but they absorb carbon dioxide readily and attack the glass of bottles, thereby losing strength; sodium carbonate may be weighed directly if its purity is assured, but the presence of carbonic acid from the carbonate is a disadvantage with many indicators; barium hydroxide solutions may be prepared which are entirely free from carbon dioxide, and such solutions immediately show by precipitation any contamination from absorption, but the hydroxide is not freely soluble in water; ammonia does not absorb carbon dioxide as readily as the caustic alkalies, but its solutions cannot be boiled nor can they be used with all indicators. The choice of a solution must depend upon the nature of the work in hand.

A !normal acid solution! should contain in one liter that quantity of the reagent which represents 1 gram of hydrogen replaceable by a base. For example, the normal solution of hydrochloric acid (HCl) should contain 36.46 grams of gaseous hydrogen chloride, since that amount furnishes the requisite 1 gram of replaceable hydrogen. On the other hand, the normal solution of sulphuric acid (H_{2}SO_{4}) should contain only 49.03 grams, i.e., one half of its molecular weight in grams.

A !normal alkali solution! should contain sufficient alkali in a liter to replace 1 gram of hydrogen in an acid. This quantity is represented by the molecular weight in grams (40.01) of sodium hydroxide (NaOH), while a sodium carbonate solution (Na_{2}CO_{3}) should contain but one half the molecular weight in grams (i.e., 53.0 grams) in a liter of normal solution.

Half-normal or tenth-normal solutions are employed in most analyses (except in the case of the less soluble barium hydroxide). Solutions of the latter strength yield more accurate results when small percentages of acid or alkali are to be determined.

INDICATORS

It has already been pointed out that the purpose of an indicator is to mark (usually by a change of color) the point at which just enough of the titrating solution has been added to complete the chemical change which it is intended to bring about. In the neutralization processes which are employed in the measurement of alkalies (!alkalimetry!) or acids (!acidimetry!) the end-point of the reaction should, in principle, be that of complete neutrality. Expressed in terms of ionic reactions, it should be the point at which the H^{+} ions from an acid[Note 1] unite with a corresponding number of OH^{-} ions from a base to form water molecules, as in the equation

H^{+}, Cl^{-} + Na^{+}, OH^{-} -> Na^{+}, Cl^{-} + (H_{2}O).

It is not usually possible to realize this condition of exact neutrality, but it is possible to approach it with sufficient exactness for analytical purposes, since substances are known which, in solution, undergo a sharp change of color as soon as even a minute excess of H^{+} or OH^{-} ions are present. Some, as will be seen, react sharply in the presence of H^{+} ions, and others with OH^{-} ions. These substances employed as indicators are usually organic compounds of complex structure and are closely allied to the dyestuffs in character.

[Note 1: A knowledge on the part of the student of the ionic theory as applied to aqueous solutions of electrolytes is assumed. A brief outline of the more important applications of the theory is given in the Appendix.]

BEHAVIOR OF ORGANIC INDICATORS

The indicators in most common use for acid and alkali titrations are methyl orange, litmus, and phenolphthalein.

In the following discussion of the principles underlying the behavior of the indicators as a class, methyl orange and phenolphthalein will be taken as types. It has just been pointed out that indicators are bodies of complicated structure. In the case of the two indicators named, the changes which they undergo have been carefully studied by Stieglitz (!J. Am. Chem. Soc.!, 25, 1112) and others, and it appears that the changes involved are of two sorts: First, a rearrangement of the atoms within the molecule, such as often occurs in organic compounds; and, second, ionic changes. The intermolecular changes cannot appropriately be discussed here, as they involve a somewhat detailed knowledge of the classification and general behavior of organic compounds; they will, therefore, be merely alluded to, and only the ionic changes followed.

Methyl orange is a representative of the group of indicators which, in aqueous solutions, behave as weak bases. The yellow color which it imparts to solutions is ascribed to the presence of the undissociated base. If an acid, such as HCl, is added to such a solution, the acid reacts with the indicator (neutralizes it) and a salt is formed, as indicated by the equation:

(M.o.)^{+}, OH^{-} + H^{+}, Cl^{-} -> (M.o.)^{+} Cl^{-} + (H_{2}O).

This salt ionizes into (M.o.)^{+} (using this abbreviation for the positive complex) and Cl^{-}; but simultaneously with this ionization there appears to be an internal rearrangement of the atoms which results in the production of a cation which may be designated as (M'.o'.)^{+}, and it is this which imparts a characteristic red color to the solution. As these changes occur in the presence of even a very small excess of acid (that is, of H^{+} ions), it serves as the desired index of their presence in the solution. If, now, an alkali, such as NaOH, is added to this reddened solution, the reverse series of changes takes place. As soon as the free acid present is neutralized, the slightest excess of sodium hydroxide, acting as a strong base, sets free the weak, little-dissociated base of the indicator, and at the moment of its formation it reverts, because of the rearrangement of the atoms, to the yellow form:

OH^{-} + (M'.o'.)^{+} -> [M'.o'.OH] -> [M.o.OH].

Phenolphthalein, on the other hand, is a very weak, little-dissociated acid, which is colorless in neutral aqueous solution or in the presence of free H^{+} ions. When an alkali is added to such a solution, even in slight excess, the anion of the salt which has formed from the acid of the indicator undergoes a rearrangement of the atoms, and a new ion, (Ph')^{+}, is formed, which imparts a pink color to the solution:

H^{+}, (Ph)^{-} + Na^{+}, OH^{-} -> (H_{2}O) + Na^{+}, (Ph)^{-} -> Na^{+}, (Ph')^{-}

The addition of the slightest excess of an acid to this solution, on the other hand, occasions first the reversion to the colorless ion and then the setting free of the undissociated acid of the indicator:

H^{+}, (Ph')^{-} -> H^{+}, (Ph)^{-} -> (HPh).

Of the common indicators methyl orange is the most sensitive toward alkalies and phenolphthalein toward acids; the others occupy intermediate positions. That methyl orange should be most sensitive toward alkalies is evident from the following considerations: Methyl orange is a weak base and, therefore, but little dissociated. It should, then, be formed in the undissociated condition as soon as even a slight excess of OH^{-} ions is present in the solution, and there should be a prompt change from red to yellow as outlined above. On the other hand, it should be an unsatisfactory indicator for use with weak acids (acetic acid, for example) because the salts which it forms with such acids are, like all salts of that type, hydrolyzed to a considerable extent. This hydrolytic change is illustrated by the equation:

(M.o.)^{+} C_{2}H_{3}O_{2}^{-} + H^{+}, OH^{-} -> [M.o.OH] + H^{+},

C_{2}H_{3}O_{2}^{-}.

Comparison of this equation with that on page 30 will make it plain that hydrolysis is just the reverse of neutralization and must, accordingly, interfere with it. Salts of methyl orange with weak acids are so far hydrolyzed that the end-point is uncertain, and methyl orange cannot be used in the titration of such acids, while with the very weak acids, such as carbonic acid or hydrogen sulphide (hydrosulphuric acid), the salts formed with methyl orange are, in effect, completely hydrolyzed (i.e., no neutralization occurs), and methyl orange is accordingly scarcely affected by these acids. This explains its usefulness, as referred to later, for the titration of strong acids, such as hydrochloric acid, even in the presence of carbonates or sulphides in solution.

Phenolphthalein, on the other hand, should be, as it is, the best of the common indicators for use with weak acids. For, since it is itself a weak acid, it is very little dissociated, and its nearly undissociated, colorless molecules are promptly formed as soon as there is any free acid (that is, free H^{+} ions) in the solution. This indicator cannot, however, be successfully used with weak bases, even ammonium hydroxide; for, since it is weak acid, the salts which it forms with weak alkalies are easily hydrolyzed, and as a consequence of this hydrolysis the change of color is not sharp. This indicator can, however, be successfully used with strong bases, because the salts which it forms with such bases are much less hydrolyzed and because the excess of OH^{-} ions from these bases also diminishes the hydrolytic action of water.

This indicator is affected by even so weak an acid as carbonic acid, which must be removed by boiling the solution before titration. It is the indicator most generally employed for the titration of organic acids.

In general, it may be stated that when a strong acid, such as hydrochloric, sulphuric or nitric acid, is titrated against a strong base, such as sodium hydroxide, potassium hydroxide, or barium hydroxide, any of these indicators may be used, since very little hydrolysis ensues. It has been noted above that the color change does not occur exactly at theoretical neutrality, from which it follows that no two indicators will show exactly the same end-point when acids and alkalis are brought together. It is plain, therefore, that the same indicator must be employed for both standardization and analysis, and that, if this is done, accurate results are obtainable.

The following table (Note 1) illustrates the variations in the volume of an alkali solution (tenth-normal sodium hydroxide) required to produce an alkaline end-point when run into 10 cc. of tenth-normal sulphuric acid, diluted with 50 cc. of water, using five drops of each of the different indicator solutions.

==================================================================== | | | | INDICATOR | N/10 | N/10 |COLOR IN ACID|COLOR IN ALKA- | H_{2}SO_{4}| NaOH |SOLUTION |LINE SOLUTION _______________|____________|__________|_____________|______________ | cc. | cc. | cc. | Methyl orange | 10 | 9.90 | Red | Yellow Lacmoid | 10 | 10.00 | Red | Blue Litmus | 10 | 10.00 | Red | Blue Rosalic acid | 10 | 10.07 | Yellow | Pink Phenolphthalein| 10 | 10.10 | Colorless | Pink ====================================================================

It should also be stated that there are occasionally secondary changes, other than those outlined above, which depend upon the temperature and concentration of the solutions in which the indicators are used. These changes may influence the sensitiveness of an indicator. It is important, therefore, to take pains to use approximately the same volume of solution when standardizing that is likely to be employed in analysis; and when it is necessary, as is often the case, to titrate the solution at boiling temperature, the standardization should take place under the same conditions. It is also obvious that since some acid or alkali is required to react with the indicator itself, the amount of indicator used should be uniform and not excessive. Usually a few drops of solution will suffice.

The foregoing statements with respect to the behavior of indicators present the subject in its simplest terms. Many substances other than those named may be employed, and they have been carefully studied to determine the exact concentration of H^{+} ions at which the color change of each occurs. It is thus possible to select an indicator for a particular purpose with considerable accuracy. As data of this nature do not belong in an introductory manual, reference is made to the following papers or books in which a more extended treatment of the subject may be found:

Washburn, E.W., Principles of Physical Chemistry (McGraw-Hill Book

Co.), (Second Edition, 1921), pp. 380-387.

Prideaux, E.B.R., The Theory and Use of Indicators (Constable & Co.,

Ltd.), (1917).

Salm, E., A Study of Indicators, !Z. physik. Chem.!, 57 (1906), 471-501.

Stieglitz, J., Theories of Indicators, !J. Am. Chem. Soc.!, 25 (1903), 1112-1127.

Noyes, A.A., Quantitative Applications of the Theory of Indicators to

Volumetric Analysis, !J. Am. Chem. Soc.!, 32 (1911), 815-861.

Bjerrum, N., General Discussion, !Z. Anal. Chem.!, 66 (1917), 13-28 and 81-95.

Ostwald, W., Colloid Chemistry of Indicators, !Z. Chem. Ind.

Kolloide!, 10 (1912), 132-146.

[Note 1: Glaser, !Indikatoren der Acidimetrie und Alkalimetrie!.

Wiesbaden, 1901.]

PREPARATION OF INDICATOR SOLUTIONS

A !methyl orange solution! for use as an indicator is commonly made by dissolving 0.05-0.1 gram of the compound (also known as Orange III) in a few cubic centimeters of alcohol and diluting with water to 100 cc. A good grade of material should be secured. It can be successfully used for the titration of hydrochloric, nitric, sulphuric, phosphoric, and sulphurous acids, and is particularly useful in the determination of bases, such as sodium, potassium, barium, calcium, and ammonium hydroxides, and even many of the weak organic bases. It can also be used for the determination, by titration with a standard solution of a strong acid, of the salts of very weak acids, such as carbonates, sulphides, arsenites, borates, and silicates, because the weak acids which are liberated do not affect the indicator, and the reddening of the solution does not take place until an excess of the strong acid is added. It should be used in cold, not too dilute, solutions. Its sensitiveness is lessened in the presence of considerable quantities of the salts of the alkalies.

A !phenolphthalein solution! is prepared by dissolving 1 gram of the pure compound in 100 cc. of 95 per cent alcohol. This indicator is particularly valuable in the determination of weak acids, especially organic acids. It cannot be used with weak bases, even ammonia. It is affected by carbonic acid, which must, therefore, be removed by boiling when other acids are to be measured. It can be used in hot solutions. Some care is necessary to keep the volume of the solutions to be titrated approximately uniform in standardization and in analysis, and this volume should not in general exceed 125-150 cc. for the best results, since the compounds formed by the indicator undergo changes in very dilute solution which lessen its sensitiveness.

The preparation of a !solution of litmus! which is suitable for use as an indicator involves the separation from the commercial litmus of azolithmine, the true coloring principle. Soluble litmus tablets are often obtainable, but the litmus as commonly supplied to the market is mixed with calcium carbonate or sulphate and compressed into lumps. To prepare a solution, these are powdered and treated two or three times with alcohol, which dissolves out certain constituents which cause a troublesome intermediate color if not removed. The alcohol is decanted and drained off, after which the litmus is extracted with hot water until exhausted. The solution is allowed to settle for some time, the clear liquid siphoned off, concentrated to one-third its volume and acetic acid added in slight excess. It is then concentrated to a sirup, and a large excess of 95 per cent. alcohol added to it. This precipitates the blue coloring matter, which is filtered off, washed with alcohol, and finally dissolved in a small volume of water and diluted until about three drops of the solution added to 50 cc. of water just produce a distinct color. This solution must be kept in an unstoppered bottle. It should be protected from dust by a loose plug of absorbent cotton. If kept in a closed bottle it soon undergoes a reduction and loses its color, which, however, is often restored by exposure to the air.

Litmus can be employed successfully with the strong acids and bases, and also with ammonium hydroxide, although the salts of the latter influence the indicator unfavorably if present in considerable concentration. It may be employed with some of the stronger organic acids, but the use of phenolphthalein is to be preferred.

PREPARATION OF STANDARD SOLUTIONS

!Hydrochloric Acid and Sodium Hydroxide. Approximate Strength!, 0.5 N

PROCEDURE.-Measure out 40 cc. of concentrated, pure hydrochloric acid into a clean liter bottle, and dilute with distilled water to an approximate volume of 1000 cc. Shake the solution vigorously for a full minute to insure uniformity. Be sure that the bottle is not too full to permit of a thorough mixing, since lack of care at this point will be the cause of much wasted time (Note 1).

Weigh out, upon a rough balance, 23 grams of sodium hydroxide (Note 2). Dissolve the hydroxide in water in a beaker. Pour the solution into a liter bottle and dilute, as above, to approximately 1000 cc. This bottle should preferably have a rubber stopper, as the hydroxide solution attacks the glass of the ground joint of a glass stopper, and may cement the stopper to the bottle. Shake the solution as described above.

[Note 1: The original solutions are prepared of a strength greater than 0.5 N, as they are more readily diluted than strengthened if later adjustment is desired.

Too much care cannot be taken to insure perfect uniformity of solutions before standardization, and thoroughness in this respect will, as stated, often avoid much waste of time. A solution once thoroughly mixed remains uniform.]

[Note 2: Commercial sodium hydroxide is usually impure and always contains more or less carbonate; an allowance is therefore made for this impurity by placing the weight taken at 23 grams per liter. If the hydroxide is known to be pure, a lesser amount (say 21 grams) will suffice.]

COMPARISON OF ACID AND ALKALI SOLUTIONS

PROCEDURE.-Rinse a previously calibrated burette three times with the hydrochloric acid solution, using 10 cc. each time, and allowing the liquid to run out through the tip to displace all water and air from that part of the burette. Then fill the burette with the acid solution. Carry out the same procedure with a second burette, using the sodium hydroxide solution.

The acid solution may be placed in a plain or in a glass-stoppered burette as may be more convenient, but the alkaline solution should never be allowed to remain long in a glass-stoppered burette, as it tends to cement the stopper to the burette, rendering it useless. It is preferable to use a plain burette for this solution.

When the burettes are ready for use and all air bubbles displaced from the tip (see Note 2, page 17) note the exact position of the liquid in each, and record the readings in the notebook. (Consult page 188.) Run out from the burette into a beaker about 40 cc. of the acid and add two drops of a solution of methyl orange; dilute the acid to about 80 cc. and run out alkali solution from the other burette, stirring constantly, until the pink has given place to a yellow. Wash down the sides of the beaker with a little distilled water if the solution has spattered upon them, return the beaker to the acid burette, and add acid to restore the pink; continue these alternations until the point is accurately fixed at which a single drop of either solutions served to produce a distinct change of color. Select as the final end-point the appearance of the faintest pink tinge which can be recognized, or the disappearance of this tinge, leaving a pure yellow; but always titrate to the same point (Note 1). If the titration has occupied more than the three minutes required for draining the sides of the burette, the final reading may be taken immediately and recorded in the notebook.

Refill the burettes and repeat the titration. From the records of calibration already obtained, correct the burette readings and make corrections for temperature, if necessary. Obtain the ratio of the sodium hydroxide solution to that of hydrochloric acid by dividing the number of cubic centimeters of acid used by the number of cubic centimeters of alkali required for neutralization. The check results of the two titrations should not vary by more than two parts in one thousand (Note 2). If the variation in results is greater than this, refill the burettes and repeat the titration until satisfactory values are obtained. Use a new page in the notebook for each titration. Inaccurate values should not be erased or discarded. They should be retained and marked "correct" or "incorrect," as indicated by the final outcome of the titrations. This custom should be rigidly followed in all analytical work.

[Note 1: The end-point should be chosen exactly at the point of change; any darker tint is unsatisfactory, since it is impossible to carry shades of color in the memory and to duplicate them from day to day.]

[Note 2: While variation of two parts in one thousand in the values obtained by an inexperienced analyst is not excessive, the idea must be carefully avoided that this is a standard for accurate work to be !generally applied!. In many cases, after experience is gained, the allowable error is less than this proportion. In a few cases a larger variation is permissible, but these are rare and can only be recognized by an experienced analyst. It is essential that the beginner should acquire at least the degree of accuracy indicated if he is to become a successful analyst.]

STANDARDIZATION OF HYDROCHLORIC ACID

SELECTION AND PREPARATION OF STANDARD

The selection of the best substance to be used as a standard for acid solutions has been the subject of much controversy. The work of Lunge (!Ztschr. angew. Chem.! (1904), 8, 231), Ferguson (!J. Soc. Chem. Ind.! (1905), 24, 784), and others, seems to indicate that the best standard is sodium carbonate prepared from sodium bicarbonate by heating the latter at temperature between 270° and 300°C. The bicarbonate is easily prepared in a pure state, and at the temperatures named the decomposition takes place according to the equation

2HNaCO_{3} -> Na_{2}CO_{3} + H_{2}O + CO_{2}

and without loss of any carbon dioxide from the sodium carbonate, such as may occur at higher temperatures. The process is carried out as described below.

PROCEDURE.-Place in a porcelain crucible about 6 grams (roughly weighed) of the purest sodium bicarbonate obtainable. Rest the crucible upon a triangle of iron or copper wire so placed within a large crucible that there is an open air space of about three eighths of an inch between them. The larger crucible may be of iron, nickel or porcelain, as may be most convenient. Insert the bulb of a thermometer reading to 350°C. in the bicarbonate, supporting it with a clamp so that the bulb does not rest on the bottom of the crucible. Heat the outside crucible, using a rather small flame, and raise the temperature of the bicarbonate fairly rapidly to 270°C. Then regulate the heat in such a way that the temperature rises !slowly! to 300°C. in the course of a half-hour. The bicarbonate should be frequently stirred with a clean, dry, glass rod, and after stirring, should be heaped up around the bulb of the thermometer in such a way as to cover it. This will require attention during most of the heating, as the temperature should not be permitted to rise above 310°C. for any length of time. At the end of the half-hour remove the thermometer and transfer the porcelain crucible, which now contains sodium carbonate, to a desiccator. When it is cold, transfer the carbonate to a stoppered weighing tube or weighing-bottle.

STANDARDIZATION

PROCEDURE.-Clean carefully the outside of a weighing-tube, or weighing-bottle, containing the pure sodium carbonate, taking care to handle it as little as possible after wiping. Weigh the tube accurately to 0.0001 gram, and record the weight in the notebook. Hold the tube over the top of a beaker (200-300 cc.) and cautiously remove the stopper, making sure that no particles fall from it or from the tube elsewhere than in the beaker. Pour out from the tube a portion of the carbonate, replace the stopper and determine approximately how much has been removed. Continue this procedure until 1.00 to 1.10 grams has been taken from the tube. Then weigh the tube accurately and record the weight under the first weight in the notebook. The difference in the two weights is the weight of the carbonate transferred to the beaker. Proceed in the same way to transfer a second portion of the carbonate from the tube to another beaker of about the same size as the first. The beakers should be labeled and plainly marked to correspond with the entries in the notebook.

Pour over the carbonate in each beaker about 80 cc. of water, stir until solution is complete, and add two drops of methyl orange solution. Fill the burettes with the standard acid and alkali solutions, noting the initial readings of the burettes and temperature of the solutions. Run in acid from the burette, stirring and avoiding loss by effervescence, until the solution has become pink. Wash down the sides of the beaker with a !little! water from a wash-bottle, and then run in alkali from the other burette until the pink is replaced by yellow; then finish the titration as described on page 37. Note the readings of the burettes after the proper interval, and record them in the notebook. Repeat the procedure, using the second portion of sodium carbonate. Apply the necessary calibration corrections to the volumes of the solutions used, and correct for temperature if necessary.

From the data obtained, calculate the volume of the hydrochloric acid solution which is equivalent to the volume of sodium hydroxide solution used in this titration. Subtract this volume from the volume of hydrochloric acid. The difference represents the volume of acid used to react with the sodium carbonate. Divide the weight of sodium carbonate by this volume in cubic centimeters, thus obtaining the weight of sodium carbonate equivalent to each cubic centimeter of the acid.

From this weight it is possible to calculate the corresponding weight of HCl in each cubic centimeter of the acid, and in turn the relation of the acid to the normal.

If, however, it is recalled that normal solutions are equivalent to each other, it will be seen that the same result may be more readily reached by dividing the weight in grams of sodium carbonate per cubic centimeter just found by titration by the weight which would be contained in the same volume of a normal solution of sodium carbonate. A normal solution of sodium carbonate contains 53.0 grams per liter, or 0.0530 gram per cc. (see page 29). The relation of the acid solution to the normal is, therefore, calculated by dividing the weight of the carbonate to which each cubic centimeter of the acid is equivalent by 0.0530. The standardization must be repeated until the values obtained agree within, at most, two parts in one thousand.

When the standard of the acid solution has been determined, calculate, from the known ratio of the two solutions, the relation of the sodium hydroxide solution to a normal solution (Notes 1 and 2).

[Note 1: In the foregoing procedure the acid solution is standardized and the alkali solution referred to this standard by calculation. It is equally possible, if preferred, to standardize the alkali solution. The standards in a common use for this purpose are purified oxalic acid (H_{2}C_{2}O_{4}.2H_{2}O), potassium acid oxalate (KHC_{2}O_{4}.H_{2}O or KHC_{2}O_{4}), potassium tetroxalate (KHC_{2}O_{4}.H_{2}C_{2}O_{4}.2H_{2}O), or potassium acid tartrate (KHC_{4}O_{6}), with the use of a suitable indicator. The oxalic acid and the oxalates should be specially prepared to insure purity, the main difficulty lying in the preservation of the water of crystallization.

It should be noted that the acid oxalate and the acid tartrate each contain one hydrogen atom replaceable by a base, while the tetroxalate contains three such atoms and the oxalic acid two. Each of the two salts first named behave, therefore, as monobasic acids, and the tetroxalate as a tribasic acid.]

[Note 2: It is also possible to standardize a hydrochloric acid solution by precipitating the chloride ions as silver chloride and weighing the precipitate, as prescribed under the analysis of sodium chloride to be described later. Sulphuric acid solutions may be standardized by precipitation of the sulphate ions as barium sulphate and weighing the ignited precipitate, but the results are not above criticism on account of the difficulty in obtaining large precipitates of barium sulphate which are uncontaminated by inclosures or are not reduced on ignition.]

DETERMINATION OF THE TOTAL ALKALINE STRENGTH OF SODA ASH

Soda ash is crude sodium carbonate. If made by the ammonia process it may contain also sodium chloride, sulphate, and hydroxide; when made by the Le Blanc process it may contain sodium sulphide, silicate, and aluminate, and other impurities. Some of these, notably the hydroxide, combine with acids and contribute to the total alkaline strength, but it is customary to calculate this strength in terms of sodium carbonate; i.e., as though no other alkali were present.

PROCEDURE.-In order to secure a sample which shall represent the average value of the ash, it is well to take at least 5 grams. As this is too large a quantity for convenient titration, an aliquot portion of the solution is measured off, representing one fifth of the entire quantity. This is accomplished as follows: Weigh out on an analytical balance two samples of soda ash of about 5 grams each into beakers of about 500 cc. capacity. (The weighings need be made to centigrams only.) Dissolve the ash in 75 cc. of water, warming gently, and filter off the insoluble residue; wash the filter by filling it at least three times with distilled water, and allowing it to drain, adding the washings to the main filtrate. Cool the filtrate to approximately the standard temperature of the laboratory, and transfer it to a 250 cc. measuring flask, washing out the beaker thoroughly. Add distilled water of laboratory temperature until the lowest point of the meniscus is level with the graduation on the neck of the flask and remove any drops of water that may be on the neck above the graduation by means of a strip of filter paper; make the solution thoroughly uniform by pouring it out into a dry beaker and back into the flask several times. Measure off 50 cc. of the solution in a measuring flask, or pipette, either of which before use should, unless they are dry on the inside, be rinsed out with at least two small portions of the soda ash solution to displace any water.

If a flask is used, fill it to the graduation with the soda ash solution and remove any liquid from the neck above the graduation with filter paper. Empty it into a beaker, and wash out the small flask, unless it is graduated for !delivery!, using small quantities of water, which are added to the liquid in the beaker. A second 50 cc. portion from the main solution should be measured off into a second beaker. Dilute the solutions in each beaker to 100 cc., add two drops of a solution of methyl orange (Note 1) and titrate for the alkali with the standard hydrochloric acid solution, using the alkali solution to complete the titration as already prescribed.

From the volumes of acid and alkali employed, corrected for burette errors and temperature changes, and the data derived from the standardization, calculate the percentage of alkali present, assuming it all to be present as sodium carbonate (Note 2).

[Note 1: The hydrochloric acid sets free carbonic acid which is unstable and breaks down into water and carbon dioxide, most of which escapes from the solution. Carbonic acid is a weak acid and, as such, does not yield a sufficient concentration of H^{+} ions to cause the indicator to change to a pink (see page 32).

The chemical changes involved may be summarized as follows:

2H^{+}, 2Cl^{-} + 2Na^{+}, CO_{3}^{-} -> 2Na^{+}, 2Cl^{-} + [H_{2}CO_{3}] -> H_{2}O + CO_{2}]

[Note 2: A determination of the alkali present as hydroxide in soda ash may be determined by precipitating the carbonate by the addition of barium chloride, removing the barium carbonate by filtration, and titrating the alkali in the filtrate.

The caustic alkali may also be determined by first using phenolphthalein as an indicator, which will show by its change from pink to colorless the point at which the caustic alkali has been neutralized and the carbonate has been converted to bicarbonate, and then adding methyl orange and completing the titration. The amount of acid necessary to change the methyl orange to pink is a measure of one half of the carbonate present. The results of the double titration furnish the data necessary for the determination of the caustic alkali and of the carbonate in the sample.]

DETERMINATION OF THE ACID STRENGTH OF OXALIC ACID

PROCEDURE.-Weigh out two portions of the acid of about 1 gram each. Dissolve these in 50 cc. of warm water. Add two drops of phenolphthalein solution, and run in alkali from the burette until the solution is pink; add acid from the other burette until the pink is just destroyed, and then add 0.3 cc. (not more) in excess. Heat the solution to boiling for three minutes. If the pink returns during the boiling, discharge it with acid and again add 0.3 cc. in excess and repeat the boiling (Note 1). If the color does not then reappear, add alkali until it does, and a !drop or two! of acid in excess and boil again for one minute (Note 2). If no color reappears during this time, complete the titration in the hot solution. The end-point should be the faintest visible shade of color (or its disappearance), as the same difficulty would exist here as with methyl orange if an attempt were made to match shades of pink.

From the corrected volume of alkali required to react with the oxalic acid, calculate the percentage of the crystallized acid (H_{2}C_{2}O_{4}.2H_{2}O) in the sample (Note 3).

[Note 1: All commercial caustic soda such as that from which the standard solution was made contains some sodium carbonate. This reacts with the oxalic acid, setting free carbonic acid, which, in turn, forms sodium bicarbonate with the remaining carbonate:

H_{2}CO_{3} + Na_{2}CO_{3} -> 2HNaCO_{3}.

This compound does not hydrolyze sufficiently to furnish enough OH^{-} ions to cause phenolphthalein to remain pink; hence, the color of the indicator is discharged in cold solutions at the point at which bicarbonate is formed. If, however, the solution is heated to boiling, the bicarbonate loses carbon dioxide and water, and reverts to sodium carbonate, which causes the indicator to become again pink:

2HNaCO_{3} -> H_{2}O + CO_{2} + Na_{2}CO_{3}.

By adding successive portions of hydrochloric acid and boiling, the carbonate is ultimately all brought into reaction.

The student should make sure that the difference in behavior of the two indicators, methyl orange and phenolphthalein, is understood.]

[Note 2: Hydrochloric acid is volatilized from aqueous solutions, except such as are very dilute. If the directions in the procedure are strictly followed, no loss of acid need be feared, but the amount added in excess should not be greater than 0.3-0.4 cc.]

[Note 3: Attention has already been called to the fact that the color changes in the different indicators occur at varying concentrations of H^{+} or OH^{-} ions. They do not indicate exact theoretical neutrality, but a particular indicator always shows its color change at a particular concentration of H^{+} or OH^{-} ions. The results of titration with a given indicator are, therefore, comparable. As a matter of fact, a small error is involved in the procedure as outlined above. The comparison of the acid and alkali solutions was made, using methyl orange as an indicator, while the titration of the oxalic acid is made with the use of phenolphthalein. For our present purposes the small error may be neglected but, if time permits, the student is recommended to standardize the alkali solution against one of the substances named in Note 1, page 41, and also to ascertain the comparative value of the acid and alkali solutions, using phenolphthalein as indicator throughout, and conducting the titrations as described above. This will insure complete accuracy.]
